BM102 - REDUCING ELBOW



1000 LBS. ( 90° Female, Reducing )

We supply and export socket welding fittings that exhibit superior functioning. These socket welding pipe fittings are designed & developed to meet diverse working conditions.
These steel socket welding fittings provide permanent welde

Reducing Elbow Pipe Fittings


  • Accurate threading, prefect right angle to 90°.
  • Screwed Female end to BSP.
  • High quality antirust oil coating.
  • Strong, Durable and Total Safety.
  • Superior grade forging to ensure crack free installation.

We have earned reputed name in making of Elbow (90A°) which is constructed with the best of Materials available in the market. alloy steel and carbon steel etc are employed for fabricating lbow. We provide these pipe fittings at market leading rates.


Nominal Size (1 x 2) A (min.) B (min.) D
8 x 6 21 22 21.50
10 x 8 22 24 21.50
15 x 10 27 32 30.00
20 x 15 32 35 36.75
25 x 15 35 43 42.50
25 x 20 38 43 42.50
32 x 25 44 51 52.00
40 x 32 48 52 59.00
50 x 40 56 64 75.00
65 x 40 60 76 91.00
65 x 50 67 76 91.00
80 x 50 73 89 104.00




Nickel Alloy
ASME SA 182 F 304, 304L, 316, 316L, 316 LN

Carbon Steel
ASTM / ASME A 105. ( Alloy Steeld connections for critical applications. )
